gate_implementation#

Implementing abstract quantum operations as instruction schedules.

Note

Note the conceptual difference between quantum operations (ops) and instruction schedules. Ops represent abstract, ideal computational operations, whereas instruction schedules represent concrete control signal sequences for the quantum computer. One can (approximately) implement an op using a number of different instruction schedules.

Full path: iqm.pulse.gate_implementation

Module Attributes

`Locus`	Sequence of QPU component physical names a quantum operation is acting on.
`OILCalibrationData`	Calibration data for a particular implementation of a particular quantum operation at a particular locus.
`OICalibrationData`	For a particular implementation of a particular quantum operation, maps operation loci to their calibration data.
`OCalibrationData`	For a particular quantum operation, maps implementation names to their calibration data.
`OpCalibrationDataTree`	Maps `quantum operation` names to their calibration data.
`NestedParams`	Nested dict defining the parameters required by GateImplementation classes.
`SINGLE_COMPONENTS_WITH_DRIVE_LOCUS_MAPPING`	Locus mapping name for mapping all components that have the drive operation defined.
`SINGLE_COMPONENTS_WITH_READOUT_LOCUS_MAPPING`	Locus mapping name for mapping all components that have the readout operation defined.
`SINGLE_COMPONENTS_WITH_FLUX_AWG_LOCUS_MAPPING`	Locus mapping name for mapping all components that have the flux operation defined and the flux controller has an AWG.
`PROBE_LINES_LOCUS_MAPPING`	Locus mapping name for mapping all probe lines.

Functions

`get_waveform_parameters`(wave[, label_prefix])	Parameters that are required to initialize the given Waveform class.
`init_subclass_composite`(gate_class)

Classes

`CompositeCache`	Cache for CompositeGate TimeBoxes.
`CompositeGate`	Base class for gate implementations that are defined in terms of other gate implementations.
`CustomIQWaveforms`	Base class for GateImplementations using custom waveform definition with IQPulses.
`GateImplementation`	ABC for implementing quantum gates and other quantum operations using instruction schedules.
`SinglePulseGate`	Base class for GateImplementations that play a single pulse on a single channel.

Inheritance
